Table B.2: Input and output currents, overload currents, Carrier frequency, surrounding air temperature and
power losses specifications
Tabla B. 2: Especificaciones de corriente de salida y entrada, corrientes de sobrecarga, frecuencia de
conmutación, temperatura alrededor del convertidor y pérdidas
Tabela B.2: Especificações de corrente de saída e entrada, correntes de sobrecarga, frequência de
chaveamento temperatura ao redor do inversor e perdas
Inverter
Convertidor
Inversor
Output Rated Current
Corriente Salida Nominal
Corrente Nominal de Saída
Overload Currents
Corrientes de Sobrecarga
Correntes de Sobrecarga
Rated Carrier Frequency
Frecuencia de Conmutación
Nominal
Frequência de Chaveamento
Nominal
Nominal Inverter Surrounding Temperature
Temperatura Nominal Alrededor del
Convertidor
Temperatura Nominal ao Redor do Inversor
Input Rated Current
Corriente de Entrada Nominal
Corrente Nominal de Entrada
Inverter Power Losses
Perdidas del Convertidor
Perdas do Inversor
IP20 with minimum free
spaces
(1)
IP20 com espacios libres
mínimos
(1)
IP20 com espaços livres
mínimos
(1)
Side-by-side IP20 or Type1
IP20 lado a lado o Nema1
IP20 lado a lado ou Nema1
Surface Mounting
Montaje en Superfície
Montagem em Superfície
(Inom) 1 min 3 s (fsw)
[Arms] [Arms] [Arms] [kHz] [Arms] [W]
CFW501A01P6T2 1.6 1.8 2.4 5 50/122 40/104 1.50 13
CFW501A02P6T2 2.6 2.9 3.9 5 50/122 40/104 2.42 18
CFW501A04P3T2 4.3 4.7 6.5 5 50/122 40/104 4.00 37
CFW501A07P0T2 7.0 7.7 10.5 5 50/122 40/104 6.50 63
CFW501A09P6T2 9.6 10.6 14.4 5 50/122 40/104 8.90 95
CFW501B07P3T2 7. 3 8.0 11.0 5 50/122 40/104 6.78 63
CFW501B10P0T2 10 11.0 15.0 5 50/122 40/104 9.30 95
CFW501B16P0T2 16 17.6 24.0 5 50/122 40/104 14.90 138
CFW501C24P0T2 24 26.4 36.0 5 50/122 40/104 22.30 183
CFW501A01P0T4 1.0 1.1 1.5 5 50/122 40/104 0.93 18
CFW501A01P6T4 1.6 1.8 2.4 5 50/122 40/104 1.50 25
CF W501A02P6T4 2.6 2.9 3.9 5 50/122 40/104 2.41 43
CF W501A04P3T4 4.3 4.7 6.5 5 50/122 40/104 4.00 66
CF W501A06P1T4 6.1 6.7 9.2 5 50/122 40/104 5.07 105
CF W501B02P6T4 2.6 2.9 3.9 5 50/122 40/104 2.40 43
CF W501B04P3T4 4.3 4.7 6.5 5 50/122 40/104 4.00 71
CFW501B06P5T4 6.5 7.2 9.8 5 50/122 40/104 6.45 109
CF W501B10P0T4 10 11.0 15.0 5 50/122 40/104 9.30 168
CF W501C14P0T4 14 15.4 21.0 5 50/122 40/104 13.00 198
CF W501C16P0T4 16 17.6 24.0 5 50/122 40/104 14.85 244
CF W501D24P0T4 24 26.4 36.0 5 50/122 40/104 22.30 405
CFW501D31P0T4 31 34.1 46.5 5 50/122 40/104 28.85 500
Note: (1) In order to meet the requirements of UL 508C, consider the ambient temperature of 40 °C (104 °F). Nota: (1) Para atender la UL 508C, considerar la temperatura ambiente de 40 °C (104 °F). Nota: (1) Para atender a UL 508C, considerar a temperatura ambiente de 40 °C (104 °F).
