3.3.2 Emission and Immunity Levels
Table 3.4: Emission and Immunity Levels
EMC Phenomenon Basic Standard Level
Emission:
Mains Terminal
Disturbance Voltage
Frequency Range: 150 kHz to 30 MHz)
IEC/EN 61800-3
It depends on the inverter model on the
length of the motor cable. Refer to table B.3.
Electromagnetic Radiation Disturbance”
Frequency Range: 30 MHz to 1000 MHz)
Immunity:
Electrostatic Discharge (ESD) IEC 61000-4-2
4 kV for contact discharge and 8 kV for air
discharge 8 kV.
Fast Transient-Burst IEC 61000-4-4
2 kV / 5 kHz (coupling capacitor) input cables.
1 kV / 5 kHz control cables and remote HMI
cables.
2 kV / 5 kHz (coupling capacitor) motor cables.
Conducted Radio-Frequency Common
Mode
IEC 61000-4-6
0.15 to 80 MHz; 10 V; 80 % AM (1 kHz).
Motor, control and HMI cables.
Surges IEC 61000-4-5
1.2/50 μs, 8/20 μs.
1 kV line-to-line coupling.
2 kV line-to-ground coupling.
Radio-Frequency Electromagnetic Field IEC 61000-4-3
80 to 1000 MHz.
10 V/m.
80 % AM (1 kHz).
Definition of Standard IEC/EM 61800-3: “Adjustable Speed Electrical Power
Drives Systems”
 Environments:
First Environment: Environments that include domestic installations, as well as
establishments directly connected without intermediate transformer to a low-voltage
power supply network which supplies buildings used for domestic purposes.
Second Environment: includes all establishments other than those directly connected to
a low-voltage power supply network that supplies buildings used for domestic purposes.
 Categories:
Category C1: inverters with a voltage rating less than 1000 V and intended for use in
the First Environment.
Category C2: inverters with a voltage rating less than 1000 V intended for use in the
First Environment, not provided with a plug connector or movable installations. They
must be installed and commissioned by a professional.
NOTE!
A professional is a person or organization familiar with the installation
and/or commissioning of inverters, including their EMC aspects.
Category C3: inverters with a voltage rating less than 1000 V and intended for use in
the Second Environment only (not designed for use in the First Environment).
