CFW501 | 141
Appendix B / Anexo B
Appendix B
Anexo B
121.4 [4.8]
185 [ 7.3]
7.2 [ 0.3]
5.5 [0.2]
2.8 [0.1]
R4 [0.2]
12.6 [0.5]
11.9 [0.5]
50 [2]
5.4 [0.2]
5.6 [0.2]
189.1 [ 7.4]
175 [6.9]
7.7 [ 0.3 ]
86.6 [3.4]
75.2 [3]
149.5 [5.9]
81 [3.2]
50 [2]
A
A
B
B
77 [3]
41.7 [1.6]
Figure B.4: Inverter dimensions in mm [in] – frame A
Figura B.4: Dimensiones del convertidor de frecuencia en mm [in] – tamaño A
Figura B.4: Dimensões do inversor em mm [in] – mecânica A
