CFW501 | 37
Optional Kits and Accessories
English
Table 7.1: Accessory models
WEG Item Name Description
Control Accessories
11950925 CFW500-CRS485 RS485 Communication Plug-in Module
Flash Memory Module
11636485 CFW500-MMF Flash Memory Module
External HMI
12254593 CFW501-HMIR Serial Remote HMI
12330016 CFW500-CCHMIR01M 1 m Serial remote HMI cable kit
12330459 CFW500-CCHMIR02M 2 m Serial remote HMI cable kit
12330460 CFW500-CCHMIR03M 3 m Serial remote HMI cable kit
12330461 CFW500-CCHMIR05M 5 m Serial remote HMI cable kit
12330462 CFW500-CCHMIR75M 7.5 m Serial remote HMI cable kit
12330463 CFW500-CCHMIR10M 10 m Serial remote HMI cable kit
Mechanical Accessories
12254653 CFW501-KN1A Nema1 kit for frame size A (standard for option N1)
12254901 CFW501-KN1B Nema1 kit for frame size B (standard for option N1)
12254902 CFW501-KN1C Nema1 Kit for frame size C (standard for option N1)
13251766 CFW501-KN1D Nema1 kit for frame size D (standard for option N1)
11951056 CFW500-KPCSA Kit for power cables shielding - frame size A (standard for option C3)
11951108 CFW500-KPCSB Kit for power cables shielding - frame size B (standard for option C3)
12133826 CFW500-KPCSC Kit for power cables shielding - frame size C (standard for option C2)
12692971 CFW500-KPCSD Kit for power cables shielding - frame size D (standard for option C3)
12473659 - Ferrite core M-049-03 (MAGNETEC)
12480705 - Ferrite core B64290-S8615-X5 (EPCOS)
Table 7.2: I/O configurations of plug-in modules
Plug-In
Module
Functions
DI AI AO DOR DOT USB CAN RS232 RS485 PROFIBUS
Source
10 V
Source
24 V
CFW500-CRS485 4 2 1 2 1 - - - 2 - 1 1
