WEG SSW-05 Plus Series User Manual

ENGLISH
Display Description
E03 Phase loss
E05 Output overload (Ixt function)
E06 External fault
E10 Error in the copy function
E2x Serial communication error
E22 Longitudinal parity fault
E24 Parameterization fault
E25 Variable or parameter not existing
E26 Expected value out of the allowed limits
E27 Writing attempt in a read only variable or logical control disabled
E29 Error of the cyclic serial communication interrupted
E31 Keypad connection fault
E63 Locked rotor
E64 Thyristor overload
E66 Overcurrent
E67 Incorrect phase sequence
E70 Undervoltage in the control supply
E71 Internal By-pass relay contact is open
E72 Overcurrent before the By-pass
E73 Overcurrent of the SSW-05 By-pass relay
E75 Frequency out of tolerance
21. ERROR CODE AND DESCRIPTION (FOR SERIAL COMMUNICATION / HMI-SSW05-RS):
Parameter Description / Notes
Releases the access to change the parameter values.
The password is 5.
Indicates the motor current in percent (%) of nominal current.
Indicates the motor current directly in Amps.
Is necessary to program P295 correctly. This is important in the correct indication value in
amperes
Indicates the version of the software installed in the CPU.
Indicates in percentage the status of the thermal motor protection (0 ... 250). 250 is the
point where the thermal motor protection trips, E05.
It sets the start voltage (%Un) that will be applied to the motor according to Figure 22.1.
When P220 = 0, the parameter content indicates the value that has been set through the
trimpot. When the trimpot has been set to the maximum value, the value indicated at the
Parameter may be lower than expected. This is due to mechanical limits variations. The
parameter content cannot be changed through the keypad when P220 = 0.
With P220=1, the content of the parameter indicates the value programmed through the
serial communication or HMI.
P000
Access Parameter
P002
Motor Current Indication
(%)
P003
Motor Current Indication
(A)
P023
Software Version
P050
Status Indication of the
Motor Thermal Protection
P101
Initial Voltage (%Un)
22. DETAILED PARAMETER DESCRIPTION (FOR SERIAL COMMUNICATION/HMI-SSW05-RS):
