P101 Initial voltage 30 ... 80 (% Un) 30 21
P102 Time of the Acceleration Ramp 1 ... 20 (s) 10 22
P104 Time of the Deceleration Ramp 0 ... 20 (s) 0 = off 22
P105
(1)
Motor Current Setting 30 ... 100 (%) 100 22
P106
(1)
Protection Configuration 0 ... 3F Hexadecimal 1F Hex. 22
P204
(1)
Load Factory Setting
0 = No function
025
1 = No function
2 = No function
3 = No function
4 = No function
5 = Load factory default
P215
(1)
Keypad Copy Function
0 = Off
025
1 = Copy (SSW -> keypad)
2 = Paste (keypad -> SSW)
P220
(1)
HMI/(Trimpots and Dip Switch) 0 = Trimpots and Dip Switch
026
Selection 1 = HMI
P264
(1)
Programmable Digital Input
0 = Not used
126
DI 1
1 = Enable / Disable
2 = External Fault
P277
(1)
Programmable relay output
1 = Full voltage
126
(14/23 - 24)
2 = Error
3 = Serial Com.
P295
(1) (2)
Rated current of the Soft-Starter
0 = 3 A
26
1 = 10 A
2 = 16 A
3 = 23 A
4 = 30 A
5 = 45 A
6 = 60 A
7 = 85 A
P308 Network Address 1 ... 30 1 26
P313
Action of the serial
1 = only Error
26
communication verification
2 = ramp disabling
3 = General disabling
4 = P264 → 1
P314
Verification Time of the
0 ... 5 (s) 0 = oFF 27
Serial Communication
Parameter
Parameter Function Range of the Factory User
Page
(Reading and Writing) Internal Values Setting Setting
20. TABLE OF PARAMETERS (FOR SERIAL COMMUNICATION / HMI-SSW05-RS):
P000
(2)
Parameter Access
0 ... 4, 6... 9999 = Read
021
5 = Alteration
P002 Motor Current Indication (%) 000,0 ... 999,9 (% In) 21
P003 Motor Current Indication (A) 000,0 ... 999,9 (A) 21
P023 Software Version 21
P050
Status Indication of the 0 ... 250
21
motor overload protection 250 = error
Parameter
Parameter Function Range of the Factory User
Page
(Reading) Internal Values Setting Setting
According
to the Type
(1)
These Parameters can be changed only with stopped motor.
(2)
These Parameters are not changed through the function “Loads Parameters with Factory Setting” (P204).
