Weil-McLain GV90+ - Interior panel

Part number 550-142-903/1016
100
&IGURE Interior panel
GV90+ Series 2 GAS-FIRED WATER BOILER — Boiler Manual
Item
number
Description Weil-McLain
part number
1 Interior panel see Figure 99, page 94,
item 8
2 Integrated boiler control assembly, includes IBC and screws 381-330-023
3 Transformer 381-356-578
4 Air pressure switch see Figure 101, page 96
item 3
not shown Wiring harness, IBC to hot surface ignitor 591-391-819
not shown Wiring harness, IBC to system and bypass circulator 591-391-824
not shown Wiring harness, Inducer/Blower 591-391-983
not shown Wiring harness, IBC to junction box 591-391-984
not shown Wiring harness, IBC to controls 591-391-985
not shown Wiring harness, Thermostat 591-392-005
not shown Wiring harness, Water Temperature Sensor 591-392-035
Replacement parts (continued)
