Weil-McLain GV90+ - Trim assembly

Part number 550-142-903/1016
98
&IGURE Trim assembly
GV90+ Series 2 GAS-FIRED WATER BOILER — Boiler Manual
Item
number
Description Weil-McLain
part number
1 System circulator, Taco 007 511-405-113
2 Bypass circulator, Taco 007 511-405-113
3 Circulator gasket, Taco 110-339 590-317-543
4
Manifold, casting/circulator kit, includes water manifold, circulator gasket (Taco
110-339) (2), square cut seal (manifold to casting)
382-200-720
5
Return manifold, recuperator/circulator kit, includes water manifold, circulator
gasket (Taco 110-339) (1), diamond gasket
382-200-721
6 Square cut seal gaskets, casting, 2.31" 572-800-011
7  590-317-535
8
Supply manifold kit, includes water manifold, circulator gasket (Taco 110-339) (1),
square cut seal (manifold to casting)
382-200-722
9 Coin-operated air vent, 1/8” NPT 570-148-565
10 Wiring harness, circulators to IBC 591-391-824
11 Return water temperature sensor and clip 511-330-089
12 Tee, 1” x 1” x ¾” Obtain locally
13 Bushing ¾” x ¼” Obtain locally
14 Temperature and Pressure Gauge, 1/4" NPT 380-000-000
15 30 PSIG Relief Valve 511-546-920
16 Nipple, NPT — ¾” x 3” Obtain locally
17 Block temperature limit switch 382-200-375
18 Boiler temperature sensor 381-356-577
19 Drain valve, ¾” NPT 511-246-392
Replacement parts (continued)
