Part number 550-142-903/1016
96
&IGURE Blower assembly
GV90+ Series 2 GAS-FIRED WATER BOILERBoiler Manual
Item
number
Description Model Weil-McLain
part number
1 
screws, igniter washers, igniter gasket
3
4
5
6
382-200-320
382-200-325
382-200-330
382-200-335
2  All 590-317-610
3 Air pressure switch (0 to 5,500 feet elevation) All 382-200-723
Air pressure switch (5,500 to 10,000 feet elevation) All 382-200-728
4 Blower motor replacement kit, includes blower motor, motor mounting
grommets, screws, lock nuts and 9" Allen wrench
All 381-356-584
5 Blower housing assembly replacement kit, includes: blower housing, obsv.
port, blower housing cover plate, blower motor mounting brackets, washer hold
down bracket, lock nuts, motor mount grommets, blower motor, blower wheel,

screws, igniter gasket
All 381-356-587
6 Conversion kit, natural to propane, includes . . . . . . . . . . . . . . . . . . . . . .

3
4
5
6
510-811-926
510-811-927
510-811-928
510-811-929
natural gas . . . . . . . . . . . . . . . . . . . . . . 3
4
5
6
510-811-934
510-811-935
510-811-936
510-811-937
7 Gas/air manifold assembly, includes gas/air manifold, gas tubing, washers,
screws, gas valve o-ring
All 382-200-362
8 Sense line condensate trap, includes sense line condensate trap and hoses All 382-200-409
10 Gas valve kit, complete, includes
gas valve, gas cock, 1/2" nipple, bracket, o-ring,
screws
All 382-200-411
12 Igniter replacement kit, includes igniter and gasket All 511-330-148
13 Igniter gasket All 590-317-599
14 Inlet air tube w/grill All 382-200-310
15 Hose clamp, 3” All 591-850-068
16 Inlet air hose, 3" by 19" long All 562-302-573
17 & 18 Inspection port cover and Inspection port gasket All see Figure 97, page 92
items 10 and 11
19 Recuperator connection gasket All 590-317-653
20 Condensate drain hose clamp All
21 Condensate trap All 560-907-716
22 ½” PVC condensate tee All
23 Condensate tee U-clamp All
24 Recuperator kit, includes recuperator, recuperator connection gasket, diamond

3 and 4
5 and 6
382-200-714
382-200-715
25  All see item 24
26  All 590-317-535
27 Flue gas thermal fuse All 511-724-295
28 
drain hose (6 inches)
All 382-200-716
29 Flue drain hose kit, 6 inches All 382-200-717
30 Recuperator vent pipe seal All 593-000-006
Replacement parts (continued)
