Weil-McLain GV90+ - Jacket assembly

Part number 550-142-903/1016
94
&IGURE Jacket assembly
GV90+ Series 2 GAS-FIRED WATER BOILER — Boiler Manual
Replacement parts (continued)
Item
number
Description Model Weil-McLain
part number
1 Jacket panel, top
3 & 4
5 & 6
382-200-739
382-200-740
2 Jacket panel, front All 382-200-702
3 Jacket panel, left side, front
3
4
5
6
382-200-730
382-200-731
382-200-732
382-200-733
4 Jacket panel, left side, rear
3 & 4
5 & 6
382-200-705
382-200-706
5 Jacket panel, right side
3 & 4
5 & 6
382-200-724
382-200-725
6 Jacket panel, rear All 382-200-726
7 Jacket brace All 422-200-192
8 Jacket panel, interior All 382-200-727
9 Base rail assembly
All see Figure 97, page 92
items 6 and 7
10
Screw, sheet metal type AB, serrated hex washer head Phillips
#10 x
1/2,” steel black phosphate
All —
