WEILER E1250
1-20
General Information
1
ELEVATOR DUMP HOPPER
1. Hopper Dump Cylinders
2. Push Frame Extension Cylinder
3. Hydraulic Vibrator
4. Baffle Cylinder
5. Hopper Baffle
6. Hopper Cleanout Cylinder
7. Hopper Cleanout Door
ELEVATOR
1. Elevator Lift Cylinder - One on each side of the elevator
DUMP HOPPER UP
1
1
3
2
BAFFLE CYLINDER
4
5
HOPPER CLEANOUT CYLINDER
7
6
ELEVATOR LIFT CYLINDERS
1
