WEILER E1250

1-21

General Information

1

CONVEYOR

1. Conveyor Lift Cylinder

2. Conveyor Swing Cylinder

3. Conveyor Clean Out Door

4.Conveyor Clean Out Door Cylinder

STEERING

1. Steering Cylinder

1

1

2

CONVEYOR CYLINDERS

4

3

STEERING CYLINDERS
