Manual R06-2016 145 / 172
ROTARY INDEXING TABLE CONTROLLER
EF2...B
DIAGNOSTICS | 11.3 Error messages
32 Error 2
Power unit type incompa-
tible
Type number: (x)
The controller is operated
by a power unit that is not
authorised for the opera-
tion.
Employ the correct power
unit type. The types PM340
and PM240-2 (as of WEISS
firmware V2.0.0) can be
used.
33 Reserve - - - -
34 Error 5
The quick stop could not
be carried out completely
(x ms)
The quick stop ramp to
stop the rotary indexing
table was not carried out
completely before acti-
vating the STO safety
function. This can cause
the table to coast down.
The quick stop was either
not selected beforehand
or interrupted in its execut-
ion. The displayed time
corresponds to the dura-
tion of the execution of the
quick stop until aborting.
Possible causes for an
abort are a premature sel-
ection of the STO safety
function or a fault occur-
ring during the quick stop
ramp.
Check wiring of the quick
stop input. When using a
motor contactor, a time
needs to be set at the
safety relay that is longer
than the time displayed on
the Overview page of the
Web interface. The time
can be optimised by the
measuring cycle quick stop
function. Check error mes-
sages that occurred during
execution of the quick stop
ramp.
35 Error 2
Error while deactivating
the PROFIBUS Dummy
DP Slave.
Error ID: (x)
The configuration cannot
be created for the inter-
face configurations "PRO-
FINET" and "Terminal/
TM15".
Contact WEISS GmbH
36 Error 5
Sensor drops The sensor monitor was
triggered while the rotary
indexing table was stan-
ding still.
Check function of the sen-
sor
37
Warning
1
Braking resistor is requi-
red
A brake resistor is requi-
red to operate the rotary
indexing table.
Connect the braking resi-
stor
Minimize load
38 Error 2
Temperature switch for
brake resistor has trigge-
red.
Temperature monitor of
the brake resistor has trig-
gered.
Wait until the brake resistor
has cooled.
Check size of the brake
resistor
Reduce load
Increase stop ramp time of
the parameter set used
39 Note -1
Fault during reading of
the Profinet device name
Controller status: RUN
The IP configuration of the
Profinet interface cannot
be set.
Check validity of the IP
address and of the subnet
mask
The configuration must not
be within the subnet of the
Ethernet interface.
Event
number
Category Reaction Event text Cause Remedy
