Manual R06-2016148 / 172
ROTARY INDEXING TABLE CONTROLLER EF2...B
DIAGNOSTICS | 11.3 Error messages
73
Warning
1
Please run the rotary
indexing table free out of
the HW limit switch in the
CW direction.
The rotary indexing table
was moved in the HW limit
switch by a motion com-
mand.
Limit switch is low active.
The corresponding error
message 71 was already
acknowledged.
Move rotary indexing table
in the CW direction out of
the HW limit switch.
Acknowledge warning
74 Reserve - - - -
75 Reserve - - - -
76 Error 4
Configuration data, rotary
indexing table are faulty
Parameter ID: (x)
There is an error in the
configuration data.
Check configuration data of
the rotary indexing table for
plausibility.
The coefficient can be used
to draw conclusions about
the affected configuration
date.
77 Reserve - - - -
78 Reserve - - - -
79 Reserve - - - -
80 Reserve - - - -
Description of the reactions
-1 No reaction (note)
0 No reaction (note, reserved for errors of the message handling)
1 No reaction (warning)
2 Execution of a stop after cycle end (error)
3 Execution of a quick stop without cancellation of the enable signal (error)
4 Execution of a quick stop with subsequent cancellation of the Enable signal (error)
5 Drive coasts down immediately (error)
Event
number
Category Reaction Event text Cause Remedy
