Manual R06-2016 147 / 172
ROTARY INDEXING TABLE CONTROLLER
EF2...B
DIAGNOSTICS | 11.3 Error messages
54 Reserve - - - -
55 Reserve - - - -
56 Reserve - - - -
57 Reserve - - - -
58 Reserve - - - -
59 Reserve - - - -
60 Reserve - - - -
61 Reserve - - - -
62 Reserve - - - -
63 Reserve - - - -
64 Reserve - - - -
65 Reserve - - - -
66 Reserve - - - -
46 Reserve - - - -
67 Reserve - - - -
68 Reserve - - - -
69 Reserve - - - -
70 Error 4
HW limit switch is actua-
ted which is approached
in the CW direction.
The rotary indexing table
was moved in the HW limit
switch by a motion com-
mand.
Limit switch is low active.
Acknowledge error mes-
sage
Move rotary indexing table
in the CCW direction out of
the HW limit switch.
Check logic of the applica-
tion program.
Check position of the HW
limit switch.
71 Error 4
HW limit switch is actua-
ted which is approached
in the CCW direction.
The rotary indexing table
was moved in the HW limit
switch by a motion com-
mand.
Limit switch is low active.
Acknowledge error mes-
sage
Move rotary indexing table
in the CW direction out of
the HW limit switch.
Check logic of the applica-
tion program.
Check position of the HW
limit switch.
72
Warning
1
Please run the rotary
indexing table free out of
the HW limit switch in the
CCW direction.
The rotary indexing table
was moved in the HW limit
switch by a motion com-
mand.
Limit switch is low active.
The corresponding error
message 70 was already
acknowledged.
Move rotary indexing table
in the CCW direction out of
the HW limit switch.
Acknowledge warning
Event
number
Category Reaction Event text Cause Remedy
