Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 124
5 Control 1 Setpoint Selection
6 Control 2 Setpoint Selection
7 Control 1 Pretune Enable/Disable
8 Control 2 Pretune Enable/Disable
9 Control 1 Selftune Enable/Disable
10 Control 2 Selftune Enable/Disable
11 Clear All Latched Outputs
12 Recorder Start/Stop
13 Profile Run/Hold
14 Profile Abort
15 Profile Hold Release
16 Force Output 1 on/off
17 Force Output 2 on/off
18 Force Output 2B on/off
19 Force Output 3 on/off
20 Force Output 3B on/off
21 Force Output 4 on/off
22 Force Output 5 on/off
23 Output 1 Clear Latch
24 Output 2 Clear Latch
25 Output 2B Clear Latch
26 Output 3 Clear Latch
27 Output 3B Clear Latch
28 Output 4 Clear Latch
29 Output 5 Clear Latch
30 Up Key Press Mimic
31 Down Key Press Mimic
32 Back Key Press Mimic
33 Right Key Press Mimic
Digital Input C2 Usage Value Usage for Digital Input C2
Dec 10022 26406 52812
RW
0 Unused
Hex 2726 6726 CE4C
1 Control 1 Enable Disable
2 Control 2 Enable Disable
3 Control 1 Auto/Manual
4 Control 2 Auto/Manual
5 Control 1 Setpoint Selection
6 Control 2 Setpoint Selection
7 Control 1 Pretune Enable/Disable
8 Control 2 Pretune Enable/Disable
9 Control 1 Selftune Enable/Disable
10 Control 2 Selftune Enable/Disable
11 Clear All Latched Outputs
12 Recorder Digital Start/Stop Trigger
13 Profile Run/Hold
14 Profile Abort
15 Profile Hold Release
16 Force Output 1 on/off
17 Force Output 2 on/off
18 Force Output 2B on/off
