Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 255
24 Pro-EC44 Product Coding
Model Code
EC44 - 0
- x - x - x - x - x - x - x - x - x - x - x - x - x -
Sxxx
Controller/Recorder
Controller C
Controller with USB Port U
Controller/Recorder X
Controller/Recorder with USB Port R
Profiler
Not fitted 0
Profiler P
Supply Voltage
100-240VAC 0
24-48V AC/DC 2
Control Loops
One Control Loop 1
One Loop + Auxiliary Input A
Two Control Loops 2
Base Option 1
Relay Output 1
Relay Output + Linear DC Output M
Base Option 2
Not fitted 0
Relay Output + Linear DC Output M
Plug-in Module Slot 1
Not fitted 0
Relay Output 1
SSR Driver Output 2
Linear DC Output L
Triac Output 8
Plug-in Module Slot 2
Not fitted 0
Relay Output 1
SSR Driver Output 2
Triac Output 8
Dual Relay Output 9
Dual SSR Driver Output Y
24VDC Transmitter Power Supply T
Plug-in Module Slot 3
Not fitted 0
Relay Output 1
SSR Driver Output 2
Triac Output 8
Dual Relay Output 9
Dual SSR Driver Output Y
24VDC Transmitter Power Supply T
Plug-in Module Slot A
Not fitted 0
RS485 Serial Comms - Modbus RTU 1
Single Digital Input 3
Auxiliary Input A 4
Ethernet Port - Modbus TCP 5 continued…
