West Control Solutions Pro-EC44 - Linear Output 7 Parameters

Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 148
Output 6 Retransmit Input 1 Maximum Value For Loop 1 Retransmit Maximum
Dec 2183 18567 37134
RW
Displayed value at which the retransmission output reaches its
maximum level (e.g. 2mA if type is 4-20mA).
Adjustable from -9999 to 9999.9
Hex 0887 4887 910E
Output 6 Retransmit Input 2 Minimum Value For Loop 2 Retransmit Minimum
Dec 2430 18814 37628
RW
Displayed value at which the retransmission output reaches its
minimum level (e.g. 4mA if type is 4-20mA).
Adjustable from -9999 to 9999.9
Hex 097E 497E 92FC
Output 6 Retransmit Input 2 Maximum Value For Loop 2 Retransmit Maximum
Dec 2431 18815 37630
RW
Displayed value at which the retransmission output reaches its
maximum level (e.g. 2mA if type is 4-20mA).
Adjustable from -9999 to 9999.9
Hex 097F 497F 92FE
Linear Output 7 Parameters
Parameter Name & Register Address
Integer Int +1 Float Access Values & Descriptions
Linear Output 7 Fitted Value Linear Output 7 Fitted
Dec 3026 19410 38820
RO
0 Not fitted
Hex 0BD2 4BD2 97A4
1 Fitted
Linear Output 7 Usage Value Output 6 Function
Dec 2203 18587 37174
RW
0 Disabled
Hex 089B 489B 9136
1 Loop 1 Primary Output Power
2 Loop 1 Secondary Output Power
3 Retransmit Loop 1 Actual Setpoint Value
4 Retransmit Input 1 Process Variable Value
5 Loop 2 Primary Output Power
6 Loop 2 Secondary Output Power
7 Retransmit Loop 2 Actual Setpoint Value
8 Retransmit Input 2 Process Variable Value
Linear mA/V DC Output 7 Type Value Linear Output 6 Type
Dec 3021 19405 38810
RW
0 0 to 5V DC
Hex 0BCD 4BCD 979A
1 0 to 10V DC
2 2 to 10V DC
3 0 to 20mA DC
4 4 to 20mA DC
5 Variable 0 to 10VDC Transmitter PSU
Linear Output 7 Level Status Linear Output % Value
Dec 3024 19408 38816
RO
-2.0% to 102.0% of output nominal range
(control output will over/under drive by 2%).
Hex 0BD0 4BD0 97A0
Output 7 Retransmit Input 1 Minimum Value For Loop 1 Retransmit Minimum
Dec 2211 18595 37190
RW
Displayed value at which the retransmission output reaches its
minimum level (e.g. 4mA if type is 4-20mA).
Adjustable from -9999 to 9999.9
Hex 08A3 48A3 9146
Output 7 Retransmit Input 1 Maximum Value For Loop 1 Retransmit Maximum
Dec 2212 18596 37192
RW
Displayed value at which the retransmission output reaches its
maximum level (e.g. 2mA if type is 4-20mA).
Adjustable from -9999 to 9999.9
Hex 08A4 48A4 9148
Output 7 Retransmit Input 2 Minimum Value For Loop 2 Retransmit Minimum
Dec 2460 18844 37688
RW
Displayed value at which the retransmission output reaches its
minimum level (e.g. 4mA if type is 4-20mA).
Adjustable from -9999 to 9999.9
Hex 099C 499C 9338
