Operator Access To Setpoint Edit Value Operator Access To Edit Loop 1 Setpoint
Dec 4128 20512 41024
RW
0 No
Hex 1020 5020 A040
1 Yes
Loop 1 Selected Setpoint Value Selected Setpoint For Loop 1
Dec 4127 20511 41022
RO
0 Main Setpoint
Hex 101F 501F A03E
1 Alternate setpoint
Loop 1 Actual Setpoint Effective Setpoint Value Of Selected Loop 1 Setpoint
Dec 8256 24640 49280
RO
The effective setpoint for loop 1
(current instantaneous value of the active setpoint source)
Hex 2040 6040 C080
Loop 2 Setpoint Parameters
Parameter Name & Register Address
Integer Int +1 Float Access Values & Descriptions
Loop 2 Setpoint Minimum Minimum Allowed Setpoint For Loop 2
Dec 3950 20334 40668
RW
Valid between the scaled input lower & upper limits
Hex 0F6E 4F6E 9EDC
Loop 2 Setpoint Maximum Maximum Allowed Setpoint For Loop 2
Dec 3951 20335 40670
RW
Valid between the scaled input lower & upper limits
Hex 0F6F 4F6F 9EDE
Loop 2 Main Local Setpoint Value Main Setpoint Value For Loop 2
Dec 3964 20348 40696
RW
Valid between Setpoint Maximum and Minimum
Hex 0F7C 4F7C 9EF8
Loop 2 Main Local Setpoint Offset Offset Of Main Setpoint Of Loop 2
Dec 3965 20349 40698
RW
Changes effective setpoint (for multi-zone slaves. +ve values
added -ve values subtracted.
Setpoint always limited by Setpoint Max and Min.
Hex 0F7D 4F7D 9EFA
Loop 2 Alternate Local Setpoint Value Alternate Setpoint Value For Loop 2
Dec 3966 20350 40700
RW
Valid between Setpoint Maximum and Minimum
Hex 0F7E 4F7E 9EFC
Loop 2 Alternate Local Setpoint Offset Offset Of Alternate setpoint Of Loop 2
Dec 3967 20351 40702
RW
Changes effective setpoint (for multi-zone slaves. +ve values
added -ve values subtracted.
Setpoint always limited by Setpoint Max and Min.
Hex 0F7F 4F7F 9EFE
Loop 2 Main Setpoint Source Value Main Setpoint Source For Loop 2
Dec 4052 20436 40872
RW
0 Local Setpoint 1
Hex 0FD4 4FD4 9FA8
1 Not Used
Loop 2 Alternate Setpoint Source Value Alternate Setpoint Source For Loop 2
Dec 4053 20437 40874
RW
0 Not Used
Hex 0FD5 4FD5 9FAA
1 Local Setpoint 2
3 Input A Remote Setpoint
Loop 2 Setpoint Select Value Setpoint Select For Loop 2
Dec 4200 20584 41168
RW
0 Local Setpoint 1
Hex 1068 5068 A0D0
1 Alternate setpoint
Loop 2 Setpoint Ramp Rate Setpoint Ramp Rate For Loop 2
Dec 4201 20585 41170
RW
0 to 10000 display units per hour
(1 to 9999 is ramp rate per hour, either 0 or >10000 = Off)
Hex 1069 5069 A0D2
