Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 151
Loop 2 Target Setpoint Actual Setpoint Value Of Selected Loop 2 Setpoint
Dec 4203 20587 41174
RO
The Loop 1 target setpoint value when ramping
Hex 106B 506B A0D6
Operator Access To Setpoint Ramp
Rate
Value Operator Access To Loop 2 Setpoint Ramp Rate
Dec 4204 20588 41176
RW
0 No
Hex 106C 506C A0D8
1 Yes
Operator Access To Setpoint Edit Value Operator Access To Edit Loop 2 Setpoint
Dec 4206 20590 41180
RW
0 No
Hex 106E 506E A0DC
1 Yes
Loop 2 Selected Setpoint Value Selected Setpoint For Loop 2
Dec 4205 20589 41178
RO
0 Main Setpoint
Hex 106D 506D A0DA
1 Alternate setpoint
Loop 2 Actual Setpoint Effective Setpoint Value Of Selected Loop 2 Setpoint
Dec 8269 24653 49306
RO
The effective setpoint for loop 1
(current instantaneous value of the active setpoint source)
Hex 204D 604D C09A
Aux A Input Parameters
Parameter Name & Register Address
Integer Int +1 Float Access Values & Descriptions
Auxiliary Input A Scale Minimum Minimum Input Scaling Value
Dec 2111 18495 36990
RW
Scale value (between ±0.001 & ±10000) when input A is at
minimum value. When used for RSP, setpoint is still constrained
by setpoint limits.
Hex 083F 483F 907E
Auxiliary Input A Scale Maximum Maximum Input Scaling Value
Dec 2112 18496 36992
RW
Scale value (between ±0.001 & ±10000) when input A is at
maximum value. When used for RSP, setpoint is still constrained
by setpoint limits.
Hex 0840 4840 9080
Auxiliary Input A Offset Offset Applied To Scaled Aux A Value
Dec 2113 18497 36994
RW
Changes effective setpoint (for multi-zone slaves. +ve values
added -ve values subtracted. from +/-0.001 to 20000 units or
OFF
Hex 0841 4841 9082
Auxiliary Input A Value Auxiliary Input A Measured Value
Dec 2114 18498 36996
RO
The current input A value (scaled).
Hex 0842 4842 9084
Loop 1 Control Parameters
Parameter Name & Register Address
Integer Int +1 Float Access Values & Descriptions
Loop 1 Manual Control Select Value Auto/Manual Mode Selection
Dec 4308 20692 41384
RW
0 Automatic Mode
Hex 10D4 50D4 A1A8
1 Manual Mode
Loop 1 Control Enable Select Value Loop Control Enable/Disable
Dec 4309 20693 41386
RW
0 Disable
Hex 10D5 50D5 A1AA
1 Enable
Loop 1 Auto/Manual Operator Access Value Operator Access To Auto/Manual Control
Dec 4394 20778 41556
RW
0 Off
Hex 112A 512A A254
1 On
