Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 147
Output 5 AND Alarm Selection Bit If Bit = 1, Alarm n Is Included in AND Selection
Dec 10133 26517 53034
RW
2 Alarm 1
Hex 2795 6795 CF2A
3 Alarm 2
4 Alarm 3
5 Alarm 4
6 Alarm 5
7 Alarm 6
8 Alarm 7
Output 5 AND Event Selection Bit If Bit = 1, Event n Is Included in AND Selection
Dec 10134 26518 53036
RW
2 Event 1
Hex 2796 6796 CF2C
3 Event 2
4 Event 3
5 Event 4
6 Event 5
7 Profile Running
8 Profile End
Linear Output 6 Parameters
Parameter Name & Register Address
Integer Int +1 Float Access Values & Descriptions
Linear Output 6 Fitted Value Linear Output 6 Fitted
Dec 3016 19400 38800
RO
0 Not fitted
Hex 0BC8 4BC8 9790
1 Fitted
Linear Output 6 Usage Value Output 6 Function
Dec 2174 18558 37116
RW
0 Disabled
Hex 087E 487E 90FC
1 Loop 1 Primary Output Power
2 Loop 1 Secondary Output Power
3 Retransmit Loop 1 Actual Setpoint Value
4 Retransmit Input 1 Process Variable Value
5 Loop 2 Primary Output Power
6 Loop 2 Secondary Output Power
7 Retransmit Loop 2 Actual Setpoint Value
8 Retransmit Input 2 Process Variable Value
Linear mA/V DC Output 6 Type Value Linear Output 6 Type
Dec 3011 19395 38790
RW
0 0 to 5V DC
Hex 0BC3 4BC3 9786
1 0 to 10V DC
2 2 to 10V DC
3 0 to 20mA DC
4 4 to 20mA DC
5 Variable 0 to 10VDC Transmitter PSU
Linear Output 6 Level Status Linear Output % Value
Dec 3014 19398 38796
RO
-2.0% to 102.0% of output nominal range
(control output will over/under drive by 2%).
Hex 0BC6 4BC6 978C
Output 6 Retransmit Input 1 Minimum Value For Loop 1 Retransmit Minimum
Dec 2182 18566 37132
RW
Displayed value at which the retransmission output reaches its
minimum level (e.g. 4mA if type is 4-20mA).
Adjustable from -9999 to 9999.9
Hex 0886 4886 910C
