Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 196
Command Response Name Response Description
Low
Byte
High
Byte
Profile Number A/R A/R The number of the profile created or edited
Segments Remaining A/R A/R The number of unused segments remaining
Command Successfully 0x4F 0x4B The command requested was executed without error
Command Not Recognized 0xFF 0xFF The command is not recognized
Profile Number Invalid 0xF0 0x00 The profile number specified is not available.
Profile Name Invalid 0xF0 0x01 The profile name/characters are not valid
Start Signal Invalid 0xF0 0x02 The start signal is not recognized
Start Time Invalid 0xF0 0x03 The specified time is not within range
Start Day Invalid 0xF0 0x04 The specified day is not recognized
Starting Setpoint Invalid 0xF0 0x05 The specified starting setpoint is not recognized
Profile Recovery Invalid 0xF0 0x06 The profile recovery is not recognized
Recovery Time Invalid 0xF0 0x07 The recovery time is not within limits
Abort Action Invalid 0xF0 0x08 The abort action is not recognized
Profile Cycles Invalid 0xF0 0x09 The number of profile cycles is not within limits
Segment Number Invalid 0xF0 0x0A The segment number is not valid for this profile
Segment Type Invalid 0xF0 0x0B The segment type is not recognized
Segment Info A Invalid 0xF0 0x0C Segment information A not valid for the type defined
Segment Info B Invalid 0xF0 0x0D Segment information B is not valid for the type defined
Write Length Invalid 0xF0 0x12 The number of parameters to be written are invalid for
the function requested
Segment Setpoint Clamped 0xF0 0x13 The setpoint value entered was out of bounds. It has
been clamped within the units setpoint limits.
Segment Not Written 0xF0 0x14 The segment has not been written
Profiler Running 0xF0 0x15 The profiler is currently running so cannot be edited
Loop 1 Auto Hold Value Invalid 0xF0 0x16 The auto hold value is not within input span
Loop 2 Auto Hold Value Invalid 0xF0 0x17 The auto hold value is not within input span
Invalid number of loops 0xF0 0x18 The number of loops is not recognised
Deleting End Segment Is Invalid 0xF0 0x19 Deleting final segment (End, Join or Repeat) is denied
Already Editing A Profile 0xF0 0x1A Finish editing the profile before starting another edit
Read a Profile Header Request & Response Sequence
Read A Profile Header - Request (to instrument)
Field Name
Data
Comments
Dec Hex
Unit Address
A/R A/R
The ID address of the instrument
Function Code
23 17
Requires the multi read/write function
Read Start Address High Byte
32 20
Read Start Address Low Byte
6 6
