West Control Solutions Pro-EC44 - Calibration Reminder Parameters; Universal Process Input 1 Parameters

Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 114
Calibration Reminder Parameters
Parameter Name & Register Address
Integer Int +1 Float Access Values & Descriptions
Calibration Reminder Enable Value Calibration Reminder Status
Dec 1048 17432 34864
RW
0 Disabled
Hex 0418 4418 8830
1 Enabled
Calibration Reminder Date Value Calibration Status
Dec
n/a n/a
34866
RW
This can be entered only as a floating point number. When
converted to binary the least significant 19 bits represents the
date in this format:
Hex
n/a n/a
8832
www DDDDD MMMM YYYYYYY
YYYYYYY = YEAR
MMMM = MONTH
DDDDD = DAY OF MONTH (1-31 but must be valid)
www = Day of the week The day of week portion
is calculated from the date (Read Only).
Example with date set to 31/07/2012
Day (31) = 11111
Month (7) = 0111
Year (12) = 0001100
Bits 17 and higher are ignored when writing so 11111 0111
0001100 (64396 decimal) is just one of many possible numbers
to write as 31/07/2012, and when reading the date back, the
number returned is
10 11111 0111 0001100 (195468 decimal) because bits 17-19
are 010 (to represent “Tuesday”).
Universal Process Input 1 Parameters
Parameter Name & Register Address
Integer Int +1 Float Access Values & Descriptions
Universal Process Input 1 Type Value Process Input Type
Dec 1024 17408 34816
RW
0 B Type Thermocouple
Hex 0400 4400 8800
2 C Type Thermocouple
4 D Type Thermocouple
6 E Type Thermocouple
8 J Type Thermocouple
10 K Type Thermocouple
12 L Type Thermocouple
14 N Type Thermocouple
16 R Type Thermocouple
18 S Type Thermocouple
20 T Type Thermocouple
22 PtRh 20%: 40% Thermocouple
24 PT100 RTD
26 NI120 RTD
28 0 to 20mA DC
29 4 to 20mA DC
30 0 to 50mV DC
