Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 115
31 10 to 50mV DC
32 0 to 5V DC
33 1 to 5V DC
34 0 to 10V DC
35 2 to 10V DC
36 Potentiometer
Input 1 Engineering Units Value Engineering Units For Display
Dec 1025 17409 34818
RW
0
= None
Hex 0401 4401 8802
1 = °C (Default for Europe)
2 = °F (Default for USA)
3 = °K
4 = Bar
5 = pH
6 = %
7 = %RH
8 = PSI
Input 1 Maximum Display Decimal
Places
Value Maximum Number Of Decimal Places In Display
Dec 1026 17410 34820
RW
0 None (e.g. 1234)
Hex 0402 4402 8804
1 One (e.g. 123.4)
2 Two (e.g. 12.34)
3 Three (e.g. 1.234)
Input 1 Scaled Input Lower Limit Scaling Value Low Limit
Dec 1027 17411 34822
RW
Valid between input 1 range maximum and minimum (see
Specifications section for input details)
Hex 0403 4403 8806
Input 1 Scaled Input Upper Limit Scaling Value High Limit
Dec 1028 17412 34824
RW
Valid between input 1 range maximum and minimum (see
Specifications section for input details)
Hex 0404 4404 8808
Input 1 Process Variable Offset Single Point Calibration PV Offset
Dec 1029 17413 34826
RW
Used for Single Point Calibration of input 1
Valid between the scaled input lower & upper limits
Hex 0405 4405 880A
Input 1 Filter Time Constant Input 1 Process Input Filter Time
Dec 1030 17414 34828
RW
Valid between 0.0 and 512.0
Hex 0406 4406 880C
Input 1 Process Variable Process Input 1 Value
Dec 1031 17415 34830
RO
The current input 1 process value
Hex 0407 4407 880E
Input 1 Signal /Sensor Break Flag Value Process Input Break Status
Dec 1032 17416 34832
RO
0 Inactive
Hex 0408 4408 8810
1
Active (break detected)
Input 1 Signal Under Range Flag Value Process Input Under Range Status
Dec 1033 17417 34834
RO
0 Inactive
Hex 0409 4409 8812
1
Active (under-range detected)
Input Signal Over Range Flag Value Process Input Over Range Status
Dec 1034 17418 34836
RO
0 Inactive
Hex 040A 440A 8814
1
Active (over-range detected)
Input 1 Cold Junction Compensation Value CJC Status
Dec 1035 17419 34838
RW
0 Disabled
Hex 040B 440B 8816
1
Enabled (default)
