Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 254
Data Recorder Option
Recording Memory:
1Mb non-volatile flash memory (data retained when power is off).
Recording Interval:
1; 2; 5; 10; 15; 30 seconds or 1; 2; 5; 10; 15; 30 minutes.
Recording Capacity:
Dependant on sample rate and number of values recorded.
Example: 2 values can be recorded for 21 days at 30 second
intervals. More values or faster sample rates reduce the duration.
RTC Battery Type:
VARTA CR 1616 3V Lithium. Clock runs for >1 year without power.
RTC accuracy:
Real Time Clock error <1second per day.
Display
Display Type:
160 x 80 pixel, monochrome graphic LCD with a dual colour
(red/green) backlight.
Display Area:
66.54mm (W) x 37.42mm (H).
Display Characters:
0 to 9, a to z, A to Z, plus @ ( ) ß ö - and _
Operating Conditions
Location
Intended for indoor use only.
Ambient Temperatures
0C to 55C (operating) and -20C to 80C (storage).
Relative Humidity:
20% to 90% non-condensing.
Altitude:
Up to 2000m above sea level.
Supply Voltage & Power
(Mains versions):
Mains Supply: 100 to 240V ±10% AC 50/60Hz. Consumption 20VA
Fuse rating: 1amp type-T / Slow-blow
Supply Voltage & Power
(Low voltage versions):
AC Supply: 20 to 48V AC 50/60Hz. Consumption 5VA
DC Supply: 22 to 65V DC. Consumption 12W.
Fuse rating: 350milliamp type-T / Slow-blow
Front Panel Sealing:
To IP66 (IP65 front USB connector). IP20 behind the panel.
(IP ratings are not tested for or approved by UL)
Conformance Norms
EMI:
CE: Complies with EN61326.
Safety Standards:
CE: Complies with EN61010-1 edition 3
UL, cUL to UL61010C-1. Pollution Degree 2, Installation Category II.
Dimensions
Front Bezel Size:
1
/
4
DIN (96 x 96mm).
Mounting:
Plug-in with panel mounting fixing strap.
Panel & Cut-out Size:
Panel must be rigid with Max thickness 6.0mm (0.25inch).
Cut-out 92mm x 92mm +0.5, -0.0mm.
Depth Behind Panel:
117mm
Ventilation
20mm gap required above, below and behind.
Weight:
0.65kg maximum.
Terminals:
Screw type (combination head).
