Pro-EC44 Product Manual - 59540-2 September 2014 Page 137
Plug-in Module Slot 1 Parameters
Parameter Name & Register Address
Integer Int +1 Float Access Values & Descriptions
Plug-in Module 1 Type Value Module Fitted In Slot 1
Dec 2130 18514 37028
RO
0 None Fitted
Hex 0852 4852 90A4
1 Single Relay
2 Single SSR Driver
3 Linear mA/V DC
8 Triac
255
Error (unrecognised module)
Linear mA/V DC Output 1 Type Value Linear Output 1 Type
Dec 2131 18515 37030
RW
0 0 to 5V DC
Hex 0853 4853 90A6
1 0 to 10V DC
2 2 to 10V DC
3 0 to 20mA DC
4 4 to 20mA DC
5 Variable 0 to 10VDC Transmitter PSU
Digital Output 1 Status Value Output 1 Status (Relay, SSR Driver or Triac only)
Dec 2132 18516 37032
RO
0 Inactive
Hex 0854 4854 90A8
1 Active
Digital Output 1 Latch Enable Value Enable / Disable Latching Of Output
Dec 2135 18519 37038
RW
0 Disable
Hex 0857 4857 90AE
1 Enable
Digital Output 1 Clear Latch Value Latch Clear
Dec 2136 18520 37040
RW
0 Do Nothing
Hex 0858 4858 90B0
1 Clear Latch
Digital Output 1 Latch State Value Latch State
Dec 2137 18521 37042
RO
0 Unlatched
Hex 0859 4859 90B2
1 Latched
Linear Output 1 Level Status Linear Output % Value
Dec 2134 18518 37036
RO
-2.0% to 102.0% of output nominal range
(control output will over/under drive by 2%).
Hex 0856 4856 90AC
Linear Output 1 Function Value Linear Output 1 Function
Dec 2144 18528 37056
RW
0 Disabled
Hex 0860 4860 90C0
1 Loop 1 Primary Output Power
2 Loop 1 Secondary Output Power
3 Retransmit Loop 1 Actual Setpoint Value
4 Retransmit Input 1 Process Variable Value
5 Loop 2 Primary Output Power
6 Loop 2 Secondary Output Power
7 Retransmit Loop 2 Actual Setpoint Value
8 Retransmit Input 2 Process Variable Value
Digital Output 1 Function Value Digital Output 1 Function
Dec 10100 26484 52968
RW
0 Disabled
Hex 2774 6774 CEE8
1 Loop 1 Primary Output Power
2 Loop 1 Secondary Output Power
3 Loop 1 VMD Open
4 Loop 1 VMD Close
