Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 136
RS485 Data Rate Value RS485 Communications Baud Rate
Dec 2118 18502 37004
RW
0 4800
Hex 0846 4846 908C
1 9600
2
19200 (Default)
3 38400
4 57600
5 115200
RS485 Parity Value Parity Used For RS485 Communications
Dec 2119 18503 37006
RW
0 None
Hex 0847 4847 908E
1 Even
2 Odd
Auxiliary Input A Type Value Auxiliary Analogue A Input Type
Dec 2120 18504 37008
RW
0 0 to 20mA DC
Hex 0848 4848 9090
1 4 to 20mA DC
2 0 to 10V DC
3 2 to 10V DC
4 0 to 5V DC
5 1 to 5V DC
Target Setpoint Address Slave Controller's Setpoint Register Address
Dec 2121 18505 37010
RW
Target setpoint parameter address for master mode
(as required by slave controller)
Hex 0849 4849 9092
Master Transmit Format Value Data Format For Setpoint Broadcast
Dec 2123 18507 37014
RW
0 Integer
Hex 084B 484B 9096
1 Integer with 1 decimal place
2 Floating point number
Master Transmit Setpoint Selection Value Source Loop Of Setpoint For Broadcast
Dec 2110 18494 36988
RW
0 Loop 1 Setpoint
Hex 083E 483E 907C
1 Loop 2 Setpoint
Comms Write Enable/Disable Value Communications Status
Dec 2124 18508 37016
RW
0 Writing via serial communications disabled
Hex 084C 484C 9098
1 Writing via serial communications enabled
Auxiliary Input A Signal Break Value Auxiliary Input A Break Status
Dec 2127 18511 37022
RO
0 Inactive
Hex 084F 484F 909E
1
Active (break detected)
Auxiliary Input A Signal Under Range Value Auxiliary Input A Under Range Status
Dec 2128 18512 37024
RO
0 Inactive
Hex 0850 4850 90A0
1
Active (under-range detected)
Auxiliary Input A Signal Over Range Value Auxiliary Input A Over Range Status
Dec 2129 18513 37026
RO
0 Inactive
Hex 0851 4851 90A2
1
Active (over-range detected)
