Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 135
Soft Digital 4 AND Digital Inputs Bit If Bit value = 1 Input n Is Included in AND Selection
Dec 10047 26431 52862
RW
0 Digital Input A
Hex 273F 673F CE7E
1 Digital Input C1
2 Digital Input C2
3 Digital Input C3
4 Digital Input C4
5 Digital Input C5
6 Digital Input C6
7 Digital Input C7
8 Digital Input C8
Soft Digital 4 OR Alarms Bit If Bit value = 1 Alarm n Is Included in OR Selection
Dec 10056 26440 52880
RW
0 Alarm 1
Hex 2748 6748 CE90
1 Alarm 2
2 Alarm 3
3 Alarm 4
4 Alarm 5
5 Alarm 6
6 Alarm 7
Soft Digital 4 OR Events Bit If Bit value = 1 Event n Is Included in OR Selection
Dec 10057 26441 52882
RW
0 Event 1
Hex 2749 6749 CE92
1 Event 2
2 Event 3
3 Event 4
4 Event 5
5 Profile Running
6 Profile End
Plug-in Module Slot A Parameters
Parameter Name & Register Address
Integer Int +1 Float Access Values & Descriptions
Digital Input A Status Value Digital Input A Status
Dec 2115 18499 36998
RO
0 Inactive
Hex 0843 4843 9086
1 Active
Option Slot A Module Type Value Module Fitted In Slot A
Dec 2116 18500 37000
RO
0 None Fitted
Hex 0844 4844 9088
1 RS485 Communications
3 Digital Input A
4 Auxiliary Input A
5 Ethernet Communications
255
Error (unrecognised module)
RS485 Address Value RS485 Communications Address
Dec 2117 18501 37002
RW
0 Modbus Master mode
Hex 0845 4845 908A
1 to 255 Modbus Slave Address
