Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 134
Soft Digital 4 Usage Value Usage for "Soft" Digital Input S4
Dec 10039 26423 52846
RW
0 Unused
Hex 2737 6737 CE6E
1 Control 1 Enable Disable
2 Control 2 Enable Disable
3 Control 1 Auto/Manual
4 Control 2 Auto/Manual
5 Control 1 Setpoint Selection
6 Control 2 Setpoint Selection
7 Control 1 Pretune Enable/Disable
8 Control 2 Pretune Enable/Disable
9 Control 1 Selftune Enable/Disable
10 Control 2 Selftune Enable/Disable
11 Clear All Latched Outputs
12 Recorder Digital Start/Stop Trigger
13 Profile Run/Hold
14 Profile Abort
15 Profile Hold Release
16 Force Output 1 on/off
17 Force Output 2 on/off
18 Force Output 2B on/off
19 Force Output 3 on/off
20 Force Output 3B on/off
21 Force Output 4 on/off
22 Force Output 5 on/off
23 Output 1 Clear Latch
24 Output 2 Clear Latch
25 Output 2B Clear Latch
26 Output 3 Clear Latch
27 Output 3B Clear Latch
28 Output 4 Clear Latch
29 Output 5 Clear Latch
30 Up Key Press Mimic
31 Down Key Press Mimic
32 Back Key Press Mimic
33 Right Key Press Mimic
Soft Digital 4 OR Digital Inputs Bit If Bit value = 1 Input n Is Included in OR Selection
Dec 10046 26430 52860
RW
0 Digital Input A
Hex 273E 673E CE7C
1 Digital Input C1
2 Digital Input C2
3 Digital Input C3
4 Digital Input C4
5 Digital Input C5
6 Digital Input C6
7 Digital Input C7
8 Digital Input C8
