West Control Solutions Pro-EC44 - Profile Setup Via Modbus

Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 187
Current Profile Running Time Current Profile Running Time
Dec 8235 24619 49238
RO
The elapsed time of the current running profile in seconds since
it began running.
Hex 202B 602B C056
Current Profile Remaining Time Current Profile Remaining Time
Dec 8236 24620 49240
RO
The remaining time for the current running profile before
reaching its end segment, in seconds
Hex 202C 602C C058
Current Segment Running Time Current Segment Running Time
Dec 8237 24621 49242
RO
The elapsed time of the current profile segment in seconds
Hex 202D 602D C05A
Current Segment Remaining Time Current Segment Remaining Time
Dec 8238 24622 49244
RO
The remaining time for the current profile segment in seconds
Hex 202E 602E C05C
Total Hold Time Total Hold Time
Dec 8239 24623 49246
RO
Total (accumulated) time the current profile has been held in
seconds
Hex 202F 602F C05E
Current Segment Loops Run Number of Current Segment Loop-backs
Dec 8240 24624 49248
RO
The number of times the current looping segment has looped
back
Hex 2030 6030 C060
Profile Setup Profile Setup via Modbus
Dec 8198 24582 49164
RW
Note: Refer to the Profile Setup Over Modbus information
below for setting up profiles via comms
Hex 2006 6006 C00C
Profile Setup via Modbus
The information in this section is intended for advanced users writing their own software
code. Most users will create or edit profiles using the instrument keypad, or using the the PC
software (available from your supplier). Either method allows quick and easy editing of
profiles.
Advanced users can setup or edit profiles by writing to the Profile Configuration parameter at
address 8198 (0x2006). This can only be accessed by using Modbus function code 23
(0x17). The instrument replies with a status message.
When creating a new profile the steps below must be followed exactly, either to create a
profile at the next available position, or at the position you specify.
Each message in the sequence includes a 2 byte Command Code that tells the instrument
the purpose of the message, and therefore the meaning of the data contained in it.
Instruction Sequence to create a profile at the next available position
1. Create a profile by writing the profile header data using the Command Code value CP
(0x43, 0x50). This starts the profile creation process by reserving a profile memory slot.
The profile number is returned by the instrument in the Edit Response Message.
Note: There is a global block on profile creation or editing via Modbus while a
profile is running. An attempt to do so returns the error code 0x15.
The only profile related commands allowed while a profile runs are the Profile
Control & Status Parameters in the previous section.
