Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 138
5 Loop 2 Primary Output Power
6 Loop 2 Secondary Output Power
7 Loop 2 VMD Open
8 Loop 2 VMD Close
9 OR Alarm Event Direct
10 OR Alarm Event Reverse
11 AND Alarm Event Direct
12 AND Alarm Event Reverse
Output 1 OR Alarm Selection Bit If Bit = 1, Alarm n Is Included in OR Selection
Dec 10107 26491 52982
RW
2 Alarm 1
Hex 277B 677B CEF6
3 Alarm 2
4 Alarm 3
5 Alarm 4
6 Alarm 5
7 Alarm 6
8 Alarm 7
Output 1 OR Event Selection Bit If Bit = 1, Event n Is Included in OR Selection
Dec 10108 26492 52984
RW
2 Event 1
Hex 277C 677C CEF8
3 Event 2
4 Event 3
5 Event 4
6 Event 5
7 Profile Running
8 Profile End
Output 1 AND Alarm Selection Bit If Bit = 1, Alarm n Is Included in AND Selection
Dec 10109 26493 52986
RW
2 Alarm 1
Hex 277D 677D CEFA
3 Alarm 2
4 Alarm 3
5 Alarm 4
6 Alarm 5
7 Alarm 6
8 Alarm 7
Output 1 AND Event Selection Bit If Bit = 1, Event n Is Included in AND Selection
Dec 10110 26494 52988
RW
2 Event 1
Hex 277E 677E CEFC
3 Event 2
4 Event 3
5 Event 4
6 Event 5
7 Profile Running
8 Profile End
Output 1 Retransmit Input 1 Minimum Value For Loop 1 Retransmit Minimum
Dec 2152 18536 37072
RW
Displayed value at which the retransmission output reaches its
minimum level (e.g. 4mA if type is 4-20mA).
Adjustable from -9999 to 9999.9
Hex 0868 4868 90D0
Output 1 Retransmit Input 1 Maximum Value For Loop 1 Retransmit Maximum
Dec 2153 18537 37074
RW
Displayed value at which the retransmission output reaches its
maximum level (e.g. 2mA if type is 4-20mA).
Adjustable from -9999 to 9999.9
Hex 0869 4869 90D2
