Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 139
Output 1 Retransmit Input 2 Minimum Value For Loop 2 Retransmit Minimum
Dec 2400 18784 37568
RW
Displayed value at which the retransmission output reaches its
minimum level (e.g. 4mA if type is 4-20mA).
Adjustable from -9999 to 9999.9
Hex 0960 4960 92C0
Output 1 Retransmit Input 2 Maximum Value For Loop 2 Retransmit Maximum
Dec 2410 18794 37588
RW
Displayed value at which the retransmission output reaches its
maximum level (e.g. 2mA if type is 4-20mA).
Adjustable from -9999 to 9999.9
Hex 096A 496A 92D4
Plug-in Module Slot 2 Parameters
Parameter Name & Register Address
Integer Int +1 Float Access Values & Descriptions
Plug-in Module 2 Type Value Module Fitted In Slot 2
Dec 2160 18544 37088
RO
0 None Fitted
Hex 0870 4870 90E0
1 Single Relay
2 Single SSR Driver
3
Error (invalid module for this slot)
8 Triac
9 Dual Relay
10 Dual SSR Driver
11 24VDC Transmitter PSU
255
Error (unrecognised module)
Output 2 or 2A Status Value Output 2 or 2A Status
Dec 2162 18546 37092
RO
0 Inactive
Hex 0872 4872 90E4
1 Active
Output 2B Status Value Output 2B Status
Dec 2163 18547 37094
RO
0 Inactive
Hex 0873 4873 90E6
1 Active
Digital Output 2 Latch Enable Value Output 2 or 2A Enable / Disable Latching
Dec 2165 18549 37098
RW
0 Disable
Hex 0875 4875 90EA
1 Enable
Digital Output 2 Clear Latch Value Output 2 or 2A Latch Clear
Dec 2166 18550 37100
RW
0 Do Nothing
Hex 0876 4876 90EC
1 Clear Latch
Digital Output 2 Latch State Value Output 2 or 2A Latch State
Dec 2167 18551 37102
RO
0 Unlatched
Hex 0877 4877 90EE
1 Latched
Digital Output 2B Latch Enable Value Output 2B Enable / Disable Latching
Dec 2168 18552 37104
RW
0 Disable
Hex 0878 4878 90F0
1 Enable
Digital Output 2B Clear Latch Value Output 2B Latch Clear
Dec 2169 18553 37106
RW
0 Do Nothing
Hex 0879 4879 90F2
1 Clear Latch
Digital Output 2B Latch State Value Output 2B Latch State
Dec 2170 18554 37108
RO
0 Unlatched
Hex 087A 487A 90F4
1 Latched
