Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 140
Output 2 or 2A Function Value Output 2 or 2A Function
Dec 10101 26485 52970
RW
0 Disabled
Hex 2775 6775 CEEA
1 Loop 1 Primary Output Power
2 Loop 1 Secondary Output Power
3 Loop 1 VMD Open
4 Loop 1 VMD Close
5 Loop 2 Primary Output Power
6 Loop 2 Secondary Output Power
7 Loop 2 VMD Open
8 Loop 2 VMD Close
9 OR Alarm Event Direct
10 OR Alarm Event Reverse
11 AND Alarm Event Direct
12 AND Alarm Event Reverse
Output 2B Function Value Output 2B Function
Dec 10102 26486 52972
RW
0 Disabled
Hex 2776 6776 CEEC
1 Loop 1 Primary Output Power
2 Loop 1 Secondary Output Power
3 Loop 1 VMD Open
4 Loop 1 VMD Close
5 Loop 2 Primary Output Power
6 Loop 2 Secondary Output Power
7 Loop 2 VMD Open
8 Loop 2 VMD Close
9 OR Alarm Event Direct
10 OR Alarm Event Reverse
11 AND Alarm Event Direct
12 AND Alarm Event Reverse
Output 2 OR Alarm Selection Bit If Bit = 1, Alarm n Is Included in OR Selection
Dec 10111 26495 52990
RW
2 Alarm 1
Hex 277F 677F CEFE
3 Alarm 2
4 Alarm 3
5 Alarm 4
6 Alarm 5
7 Alarm 6
8 Alarm 7
Output 2 OR Event Selection Bit If Bit = 1, Event n Is Included in OR Selection
Dec 10112 26496 52992
RW
2 Event 1
Hex 2780 6780 CF00
3 Event 2
4 Event 3
5 Event 4
6 Event 5
7 Profile Running
8 Profile End
