Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 141
Output 2 AND Alarm Selection Bit If Bit = 1, Alarm n Is Included in AND Selection
Dec 10113 26497 52994
RW
2 Alarm 1
Hex 2781 6781 CF02
3 Alarm 2
4 Alarm 3
5 Alarm 4
6 Alarm 5
7 Alarm 6
8 Alarm 7
Output 2 AND Event Selection Bit If Bit = 1, Event n Is Included in AND Selection
Dec 10114 26498 52996
RW
2 Event 1
Hex 2782 6782 CF04
3 Event 2
4 Event 3
5 Event 4
6 Event 5
7 Profile Running
8 Profile End
Output 2B OR Alarm Selection Bit If Bit = 1, Alarm n Is Included in OR Selection
Dec 10115 26499 52998
RW
2 Alarm 1
Hex 2783 6783 CF06
3 Alarm 2
4 Alarm 3
5 Alarm 4
6 Alarm 5
7 Alarm 6
8 Alarm 7
Output 2B OR Event Selection Bit If Bit = 1, Event n Is Included in OR Selection
Dec 10116 26500 53000
RW
2 Event 1
Hex 2784 6784 CF08
3 Event 2
4 Event 3
5 Event 4
6 Event 5
7 Profile Running
8 Profile End
Output 2B AND Alarm Selection Bit If Bit = 1, Alarm n Is Included in AND Selection
Dec 10117 26501 53002
RW
2 Alarm 1
Hex 2785 6785 CF0A
3 Alarm 2
4 Alarm 3
5 Alarm 4
6 Alarm 5
7 Alarm 6
8 Alarm 7
Output 2B AND Event Selection Bit If Bit = 1, Event n Is Included in AND Selection
Dec 10118 26502 53004
RW
2 Event 1
Hex 2786 6786 CF0C
3 Event 2
4 Event 3
5 Event 4
6 Event 5
7 Profile Running
8 Profile End
