Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 116
Input 1 Multi-point Scaling Enable Value Multi-point Scaling Status
Dec 1053 17437 34874
RW
0 Disabled
Hex 041D 441D 883A
1
Enabled (valid only if the input type is linear)
Input 1 Scale Point 1 Multi-Point Scaling Point 1
Dec 1054 17438 34876
RW
Percentage of the scaled input where multi-point scaling value 1
is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 041E 441E 883C
Input 1 Display Point 1 Multi-Point Scaling Display Value For Point 1
Dec 1055 17439 34878
RW
Value to display at multi-point scaling point 1
Valid between the scaled input lower & upper limits
Hex 041F 441F 883E
Input 1 Scale Point 2 Multi-Point Scaling Point 2
Dec 1056 17440 34880
RW
Percentage of the scaled input where multi-point scaling value 2
is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 0420 4420 8840
Input 1 Display Point 2 Multi-Point Scaling Display Value For Point 2
Dec 1057 17441 34882
RW
Value to display at multi-point scaling point 2
Valid between the scaled input lower & upper limits
Hex 0421 4421 8842
Input 1 Scale Point 3 Multi-Point Scaling Point 3
Dec 1058 17442 34884
RW
Percentage of the scaled input where multi-point scaling value 3
is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 0422 4422 8844
Input 1 Display Point 3 Multi-Point Scaling Display Value For Point 3
Dec 1059 17443 34886
RW
Value to display at multi-point scaling point 3
Valid between the scaled input lower & upper limits
Hex 0423 4423 8846
Input 1 Scale Point 4 Multi-Point Scaling Point 4
Dec 1060 17444 34888
RW
Percentage of the scaled input where multi-point scaling value 4
is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 0424 4424 8848
Input 1 Display Point 4 Multi-Point Scaling Display Value For Point 4
Dec 1061 17445 34890
RW
Value to display at multi-point scaling point 4
Valid between the scaled input lower & upper limits
Hex 0425 4425 884A
Input 1 Scale Point 5 Multi-Point Scaling Point 5
Dec 1062 17446 34892
RW
Percentage of the scaled input where multi-point scaling value 5
is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 0426 4426 884C
Input 1 Display Point 5 Multi-Point Scaling Display Value For Point 5
Dec 1063 17447 34894
RW
Value to display at multi-point scaling point 5
Valid between the scaled input lower & upper limits
Hex 0427 4427 884E
Input 1 Scale Point 6 Multi-Point Scaling Point 6
Dec 1064 17448 34896
RW
Percentage of the scaled input where multi-point scaling value 6
is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 0428 4428 8850
Input 1 Display Point 6 Multi-Point Scaling Display Value For Point 6
Dec 1065 17449 34898
RW
Value to display at multi-point scaling point 6
Valid between the scaled input lower & upper limits
Hex 0429 4429 8852
Input 1 Scale Point 7 Multi-Point Scaling Point 7
Dec 1066 17450 34900
RW
Percentage of the scaled input where multi-point scaling value 7
is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 042A 442A 8854
Input 1 Display Point 7 Multi-Point Scaling Display Value For Point 7
Dec 1067 17451 34902
RW
Value to display at multi-point scaling point 7
Valid between the scaled input lower & upper limits
Hex 042B 442B 8856
