Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 117
Input 1 Scale Point 8 Multi-Point Scaling Point 8
Dec 1068 17452 34904
RW
Percentage of the scaled input where multi-point scaling value 8
is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 042C 442C 8858
Input 1 Display Point 8 Multi-Point Scaling Display Value For Point 8
Dec 1069 17453 34906
RW
Value to display at multi-point scaling point 8
Valid between the scaled input lower & upper limits
Hex 042D 442D 885A
Input 1 Scale Point 9 Multi-Point Scaling Point 9
Dec 1070 17454 34908
RW
Percentage of the scaled input where multi-point scaling value 9
is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 042E 442E 885C
Input 1 Display Point 9 Multi-Point Scaling Display Value For Point 9
Dec 1071 17455 34910
RW
Value to display at multi-point scaling point 9
Valid between the scaled input lower & upper limits
Hex 042F 442F 885E
Input 1 Scale Point 10 Multi-Point Scaling Point 10
Dec 1072 17456 34912
RW
Percentage of the scaled input where multi-point scaling value
10 is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 0430 4430 8860
Input 1 Display Point 10 Multi-Point Scaling Display Value For Point 10
Dec 1073 17457 34914
RW
Value to display at multi-point scaling point 10
Valid between the scaled input lower & upper limits
Hex 0431 4431 8862
Input 1 Scale Point 11 Multi-Point Scaling Point 11
Dec 1074 17458 34916
RW
Percentage of the scaled input where multi-point scaling value
11 is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 0432 4432 8864
Input 1 Display Point 11 Multi-Point Scaling Display Value For Point 11
Dec 1075 17459 34918
RW
Value to display at multi-point scaling point 11
Valid between the scaled input lower & upper limits
Hex 0433 4433 8866
Input 1 Scale Point 12 Multi-Point Scaling Point 12
Dec 1076 17460 34920
RW
Percentage of the scaled input where multi-point scaling value
12 is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 0434 4434 8868
Input 1 Display Point 12 Multi-Point Scaling Display Value For Point 12
Dec 1077 17461 34922
RW
Value to display at multi-point scaling point 12
Valid between the scaled input lower & upper limits
Hex 0435 4435 886A
Input 1 Scale Point 13 Multi-Point Scaling Point 13
Dec 1078 17462 34924
RW
Percentage of the scaled input where multi-point scaling value
13 is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 0436 4436 886C
Input 1 Display Point 13 Multi-Point Scaling Display Value For Point 13
Dec 1079 17463 34926
RW
Value to display at multi-point scaling point 13
Valid between the scaled input lower & upper limits
Hex 0437 4437 886E
Input 1 Scale Point 14 Multi-Point Scaling Point 14
Dec 1080 17464 34928
RW
Percentage of the scaled input where multi-point scaling value
14 is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 0438 4438 8870
Input 1 Display Point 14 Multi-Point Scaling Display Value For Point 14
Dec 1081 17465 34930
RW
Value to display at multi-point scaling point 14
Valid between the scaled input lower & upper limits
Hex 0439 4439 8872
