Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 118
Input 1 Scale Point 15 Multi-Point Scaling Point 15
Dec 1082 17466 34932
RW
Percentage of the scaled input where multi-point scaling value
15 is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 043A 443A 8874
Input 1 Display Point 15 Multi-Point Scaling Display Value For Point 15
Dec 1083 17467 34934
RW
Value to display at multi-point scaling point 15
Valid between the scaled input lower & upper limits
Hex 043B 443B 8876
User Calibration Type Value Calibration Type
Dec 1085 17469 34938
RW
0 None (input 1 base calibration used)
Hex 043D 443D 887A
1 Single Point Calibration
2 Two Point Calibration
User Calibration Point - Low Value Two Point Calibration Low Point
Dec 1086 17470 34940
RW
The input value at which the Low Offset will be applied
Valid between input 1 scaled input lower & upper limits
Hex 043E 443E 887C
User Calibration Low Offset Two Point Calibration Low Offset Value
Dec 1087 17471 34942
RW
The Low Offset value applied to the reading at the Low
Calibration Point
0.0 to 100.0%
Hex 043F 443F 887E
User Calibration Point - High Value Two Point Calibration High Point
Dec 1088 17472 34944
RW
The input value at which the High Offset will be applied
Valid between input 1 scaled input lower & upper limits
Hex 0440 4440 8880
User Calibration High Offset Two Point Calibration High Offset Value
Dec 1089 17473 34946
RW
The High Offset value applied to the reading at the High
Calibration Point
0.0 to 100.0%
Hex 0441 4441 8882
Universal Process Input 2 Parameters
Parameter Name & Register Address
Integer Int +1 Float Access Values & Descriptions
Universal Input 2 Usage Value Process Input Type
Dec 1166 17550 35100
RW
0 Standard
Hex 048E 448E 891C
1 Feedback signal for Input 1
2
Redundant Sensor (backup for Input 1 Thermocouple
or RTD)
3
Not Used (or Indication only)
Universal Process Input 2 Type Value Process Input Type
Dec 1100 17484 34968
RW
0 B Type Thermocouple
Hex 044C 444C 8898
2 C Type Thermocouple
4 D Type Thermocouple
6 E Type Thermocouple
8 J Type Thermocouple
10 K Type Thermocouple
12 L Type Thermocouple
14 N Type Thermocouple
16 R Type Thermocouple
18 S Type Thermocouple
20 T Type Thermocouple
22 PtRh 20%: 40% Thermocouple
24 PT100 RTD
