Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 119
26 NI120 RTD
28 0 to 20mA DC
29 4 to 20mA DC
30 0 to 50mV DC
31 10 to 50mV DC
32 0 to 5V DC
33 1 to 5V DC
34 0 to 10V DC
35 2 to 10V DC
36 Potentiometer
Input 2 Engineering Units Value Engineering Units For Display
Dec 1101 17485 34970
RW
0
= None
Hex 044D 444D 889A
1 = °C (Default for Europe)
2 = °F (Default for USA)
3 = °K
4 = Bar
5 = pH
6 = %
7 = %RH
8 = PSI
Input 2 Maximum Display Decimal
Places
Value Maximum Number Of Decimal Places In Display
Dec 1102 17486 34972
RW
0 None (e.g. 1234)
Hex 044E 444E 889C
1 One (e.g. 123.4)
2 Two (e.g. 12.34)
3 Three (e.g. 1.234)
Input 2 Scaled Input Lower Limit Scaling Value Low Limit
Dec 1103 17487 34974
RW
Valid between input 2 range maximum and minimum (see
Specifications section for input details)
Hex 044F 444F 889E
Input 2 Scaled Input Upper Limit Scaling Value High Limit
Dec 1104 17488 34976
RW
Valid between input 2 range maximum and minimum (see
Specifications section for input details)
Hex 0450 4450 88A0
Input 2 Process Variable Offset Single Point Calibration PV Offset
Dec 1105 17489 34978
RW
Used for Single Point Calibration of input 2
Valid between the scaled input lower & upper limits
Hex 0451 4451 88A2
Input 2 Filter Time Constant Input 2 Process Input Filter Time
Dec 1106 17490 34980
RW
Valid between 0.0 and 512.0
Hex 0452 4452 88A4
Input 2 Process Variable Process Input 2 Value
Dec 1107 17491 34982
RO
The current input 2 process value
Hex 0453 4453 88A6
Input 2 Signal /Sensor Break Flag Value Process Input Break Status
Dec 1108 17492 34984
RO
0 Inactive
Hex 0454 4454 88A8
1
Active (break detected)
Input 2 Signal Under Range Flag Value Process Input Under Range Status
Dec 1109 17493 34986
RO
0 Inactive
Hex 0455 4455 88AA
1
Active (under-range detected)
