West Control Solutions Pro-EC44 - Page 126

Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 120
Input 2 Signal Over Range Flag Value Process Input Over Range Status
Dec 1110 17494 34988
RO
0 Inactive
Hex 0456 4456 88AC
1
Active (over-range detected)
Input 2 Cold Junction Compensation Value CJC Status
Dec 1111 17495 34990
RW
0 Disabled
Hex 0457 4457 88AE
1
Enabled (default)
Input 2 Multi-point Scaling Enable Value Multi-point Scaling Status
Dec 1129 17513 35026
RW
0 Disabled
Hex 0469 4469 88D2
1
Enabled (only if the input type is linear)
Input 2 Scale Point 1 Multi-Point Scaling Point 1
Dec 1130 17514 35028
RW
Percentage of the scaled input where multi-point scaling value 1
is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 046A 446A 88D4
Input 2 Display Point 1 Multi-Point Scaling Display Value For Point 1
Dec 1131 17515 35030
RW
Value to display at multi-point scaling point 1
Valid between the scaled input lower & upper limits
Hex 046B 446B 88D6
Input 2 Scale Point 2 Multi-Point Scaling Point 2
Dec 1132 17516 35032
RW
Percentage of the scaled input where multi-point scaling value 2
is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 046C 446C 88D8
Input 2 Display Point 2 Multi-Point Scaling Display Value For Point 2
Dec 1133 17517 35034
RW
Value to display at multi-point scaling point 2
Valid between the scaled input lower & upper limits
Hex 046D 446D 88DA
Input 2 Scale Point 3 Multi-Point Scaling Point 3
Dec 1134 17518 35036
RW
Percentage of the scaled input where multi-point scaling value 3
is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 046E 446E 88DC
Input 2 Display Point 3 Multi-Point Scaling Display Value For Point 3
Dec 1135 17519 35038
RW
Value to display at multi-point scaling point 3
Valid between the scaled input lower & upper limits
Hex 046F 446F 88DE
Input 2 Scale Point 4 Multi-Point Scaling Point 4
Dec 1136 17520 35040
RW
Percentage of the scaled input where multi-point scaling value 4
is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 0470 4470 88E0
Input 2 Display Point 4 Multi-Point Scaling Display Value For Point 4
Dec 1137 17521 35042
RW
Value to display at multi-point scaling point 4
Valid between the scaled input lower & upper limits
Hex 0471 4471 88E2
Input 2 Scale Point 5 Multi-Point Scaling Point 5
Dec 1138 17522 35044
RW
Percentage of the scaled input where multi-point scaling value 5
is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 0472 4472 88E4
Input 2 Display Point 5 Multi-Point Scaling Display Value For Point 5
Dec 1139 17523 35046
RW
Value to display at multi-point scaling point 5
Valid between the scaled input lower & upper limits
Hex 0473 4473 88E6
Input 2 Scale Point 6 Multi-Point Scaling Point 6
Dec 1140 17524 35048
RW
Percentage of the scaled input where multi-point scaling value 6
is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 0474 4474 88E8
Input 2 Display Point 6 Multi-Point Scaling Display Value For Point 6
Dec 1141 17525 35050
RW
Value to display at multi-point scaling point 6
Valid between the scaled input lower & upper limits
Hex 0475 4475 88EA
