Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 121
Input 2 Scale Point 7 Multi-Point Scaling Point 7
Dec 1142 17526 35052
RW
Percentage of the scaled input where multi-point scaling value 7
is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 0476 4476 88EC
Input 2 Display Point 7 Multi-Point Scaling Display Value For Point 7
Dec 1143 17527 35054
RW
Value to display at multi-point scaling point 7
Valid between the scaled input lower & upper limits
Hex 0477 4477 88EE
Input 2 Scale Point 8 Multi-Point Scaling Point 8
Dec 1144 17528 35056
RW
Percentage of the scaled input where multi-point scaling value 8
is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 0478 4478 88F0
Input 2 Display Point 8 Multi-Point Scaling Display Value For Point 8
Dec 1145 17529 35058
RW
Value to display at multi-point scaling point 8
Valid between the scaled input lower & upper limits
Hex 0479 4479 88F2
Input 2 Scale Point 9 Multi-Point Scaling Point 9
Dec 1146 17530 35060
RW
Percentage of the scaled input where multi-point scaling value 9
is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 047A 447A 88F4
Input 2 Display Point 9 Multi-Point Scaling Display Value For Point 9
Dec 1147 17531 35062
RW
Value to display at multi-point scaling point 9
Valid between the scaled input lower & upper limits
Hex 047B 447B 88F6
Input 2 Scale Point 10 Multi-Point Scaling Point 10
Dec 1148 17532 35064
RW
Percentage of the scaled input where multi-point scaling value
10 is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 047C 447C 88F8
Input 2 Display Point 10 Multi-Point Scaling Display Value For Point 10
Dec 1149 17533 35066
RW
Value to display at multi-point scaling point 10
Valid between the scaled input lower & upper limits
Hex 047D 447D 88FA
Input 2 Scale Point 11 Multi-Point Scaling Point 11
Dec 1150 17534 35068
RW
Percentage of the scaled input where multi-point scaling value
11 is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 047E 447E 88FC
Input 2 Display Point 11 Multi-Point Scaling Display Value For Point 11
Dec 1151 17535 35070
RW
Value to display at multi-point scaling point 11
Valid between the scaled input lower & upper limits
Hex 047F 447F 88FE
Input 2 Scale Point 12 Multi-Point Scaling Point 12
Dec 1152 17536 35072
RW
Percentage of the scaled input where multi-point scaling value
12 is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 0480 4480 8900
Input 2 Display Point 12 Multi-Point Scaling Display Value For Point 12
Dec 1153 17537 35074
RW
Value to display at multi-point scaling point 12
Valid between the scaled input lower & upper limits
Hex 0481 4481 8902
Input 2 Scale Point 13 Multi-Point Scaling Point 13
Dec 1154 17538 35076
RW
Percentage of the scaled input where multi-point scaling value
13 is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 0482 4482 8904
Input 2 Display Point 13 Multi-Point Scaling Display Value For Point 13
Dec 1155 17539 35078
RW
Value to display at multi-point scaling point 13
Valid between the scaled input lower & upper limits
Hex 0483 4483 8906
Input 2 Scale Point 14 Multi-Point Scaling Point 14
Dec 1156 17540 35080
RW
Percentage of the scaled input where multi-point scaling value
14 is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 0484 4484 8908
