Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 122
Input 2 Display Point 14 Multi-Point Scaling Display Value For Point 14
Dec 1157 17541 35082
RW
Value to display at multi-point scaling point 14
Valid between the scaled input lower & upper limits
Hex 0485 4485 890A
Input 2 Scale Point 15 Multi-Point Scaling Point 15
Dec 1158 17542 35084
RW
Percentage of the scaled input where multi-point scaling value
15 is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex 0486 4486 890C
Input 2 Display Point 15 Multi-Point Scaling Display Value For Point 15
Dec 1159 17543 35086
RW
Value to display at multi-point scaling point 15
Valid between the scaled input lower & upper limits
Hex 0487 4487 890E
User Calibration Type Value Calibration Type
Dec 1161 17545 35090
RW
0 None (input 2 base calibration used)
Hex 0489 4489 8912
1 Single Point Calibration
2 Two Point Calibration
User Calibration Point - Low Value Two Point Calibration Low Point
Dec 1162 17546 35092
RW
The input value at which the Low Offset will be applied
Valid between input 2 scaled input lower & upper limits
Hex 048A 448A 8914
User Calibration Low Offset Two Point Calibration Low Offset Value
Dec 1163 17547 35094
RW
The Low Offset value applied to the reading at the Low
Calibration Point
0.0 to 100.0%
Hex 048B 448B 8916
User Calibration Point - High Value Two Point Calibration High Point
Dec 1164 17548 35096
RW
The input value at which the High Offset will be applied
Valid between input 2 scaled input lower & upper limits
Hex 048C 448C 8918
User Calibration High Offset Two Point Calibration High Offset Value
Dec 1165 17549 35098
RW
The High Offset value applied to the reading at the High
Calibration Point
0.0 to 100.0%
Hex 048D 448D 891A
Digital Input Setup Parameters
Parameter Name & Register Address
Integer Int +1 Float Access Values & Descriptions
Invert Digital Inputs Bit If Bit = 1, Input n is Inverted (ON becomes OFF etc)
Dec 10059 26443 52886
RW
0 Digital Input A
Hex 274B 674B CE96
1 Digital Input C1
2 Digital Input C2
3 Digital Input C3
4 Digital Input C4
5 Digital Input C5
6 Digital Input C6
7 Digital Input C7
8 Digital Input C8
Profile Selection Type Value Profile Selection & Bit Pattern Format
Dec 10029 26413 52826
RW
0 None
Hex 272D 672D CE5A
1 Binary
2 BCD
