Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 126
Digital Input C4 Usage Value Usage for Digital Input C4
Dec 10024 26408 52816
RW
0 Unused
Hex 2728 6728 CE50
1 Control 1 Enable Disable
2 Control 2 Enable Disable
3 Control 1 Auto/Manual
4 Control 2 Auto/Manual
5 Control 1 Setpoint Selection
6 Control 2 Setpoint Selection
7 Control 1 Pretune Enable/Disable
8 Control 2 Pretune Enable/Disable
9 Control 1 Selftune Enable/Disable
10 Control 2 Selftune Enable/Disable
11 Clear All Latched Outputs
12 Recorder Digital Start/Stop Trigger
13 Profile Run/Hold
14 Profile Abort
15 Profile Hold Release
16 Force Output 1 on/off
17 Force Output 2 on/off
18 Force Output 2B on/off
19 Force Output 3 on/off
20 Force Output 3B on/off
21 Force Output 4 on/off
22 Force Output 5 on/off
23 Output 1 Clear Latch
24 Output 2 Clear Latch
25 Output 2B Clear Latch
26 Output 3 Clear Latch
27 Output 3B Clear Latch
28 Output 4 Clear Latch
29 Output 5 Clear Latch
30 Up Key Press Mimic
31 Down Key Press Mimic
32 Back Key Press Mimic
33 Right Key Press Mimic
Digital Input C5 Usage Value Usage for Digital Input C5
Dec 10025 26409 52818
RW
0 Unused
Hex 2729 6729 CE52
1 Control 1 Enable Disable
2 Control 2 Enable Disable
3 Control 1 Auto/Manual
4 Control 2 Auto/Manual
5 Control 1 Setpoint Selection
6 Control 2 Setpoint Selection
7 Control 1 Pretune Enable/Disable
8 Control 2 Pretune Enable/Disable
9 Control 1 Selftune Enable/Disable
10 Control 2 Selftune Enable/Disable
11 Clear All Latched Outputs
12 Recorder Digital Start/Stop Trigger
