Soft Digital 2 AND Digital Inputs Bit If Bit value = 1 Input n Is Included in AND Selection
Dec 10043 26427 52854
RW
0 Digital Input A
Hex 273B 673B CE76
1 Digital Input C1
2 Digital Input C2
3 Digital Input C3
4 Digital Input C4
5 Digital Input C5
6 Digital Input C6
7 Digital Input C7
8 Digital Input C8
Soft Digital 2 OR Alarms Bit If Bit value = 1 Alarm n Is Included in OR Selection
Dec 10052 26436 52872
RW
0 Alarm 1
Hex 2744 6744 CE88
1 Alarm 2
2 Alarm 3
3 Alarm 4
4 Alarm 5
5 Alarm 6
6 Alarm 7
Soft Digital 1 OR Events Bit If Bit value = 1 Event n Is Included in OR Selection
Dec 10053 26437 52874
RW
0 Event 1
Hex 2745 6745 CE8A
1 Event 2
2 Event 3
3 Event 4
4 Event 5
5 Profile Running
6 Profile End
Soft Digital 3 Usage Value Usage for "Soft" Digital Input S3
Dec 10038 26422 52844
RW
0 Unused
Hex 2736 6736 CE6C
1 Control 1 Enable Disable
2 Control 2 Enable Disable
3 Control 1 Auto/Manual
4 Control 2 Auto/Manual
5 Control 1 Setpoint Selection
6 Control 2 Setpoint Selection
7 Control 1 Pretune Enable/Disable
8 Control 2 Pretune Enable/Disable
9 Control 1 Selftune Enable/Disable
10 Control 2 Selftune Enable/Disable
11 Clear All Latched Outputs
12 Recorder Digital Start/Stop Trigger
13 Profile Run/Hold
14 Profile Abort
15 Profile Hold Release
16 Force Output 1 on/off
17 Force Output 2 on/off
18 Force Output 2B on/off
19 Force Output 3 on/off
20 Force Output 3B on/off
21 Force Output 4 on/off
