Alarm 1 Main Label Main Language Name For Alarm 1 In Status Screen
Dec 6151 22535 45070
RW
8 ASCII characters replacing the title "Alarm 1" in alarm status
screens when main display language is used, read/written with
Modbus functions 16 or 23. Valid characters are 0 to 9, a to z, A
to Z, plus ß ö ( ) - and _.
Hex 1807 5807 B00E
Alarm 1 Alternate Label Alternate Language Name For Alarm 1 In Status Screen
Dec 6152 22536 45072
RW
8 ASCII characters replacing the title "Alarm 1" in alarm status
screens when the alternate language is used, read/written with
Modbus functions 16 or 23. Valid characters are 0 to 9, a to z, A
to Z, plus ß ö ( ) - and _.
Hex 1808 5808 B010
Alarm 1 Minimum Duration Alarm 1 Minimum Duration
Dec 6153 22537 45074
RW
Minimum time alarm 1 must be passed its threshold before
activating (deactivation is not affected by this parameter).
From 0 to 9999 secs
Hex 1809 5809 B012
Alarm 2 Input Source Value Source
Dec 6159 22543 45086
RW
0 Input 1
Hex 180F 580F B01E
1 Input 2
2 Aux A Input
3 Control Loop 1 Primary Power
4 Control Loop 1 Secondary Power
5 Control Loop 2 Primary Power
6 Control Loop 2 Secondary Power
7 Loop 1
8 Loop 2
Alarm 2 Type Value Alarm 2 Type
Dec 6160 22544 45088
RW
0 Unused
Hex 1810 5810 B020
1 Process High Alarm
2 Process Low Alarm
3 Deviation Alarm (SP-PV)
4 Band Alarm
5 Input Rate of Change
6 Input/Sensor Break Alarm
7 Loop Alarm
10 % memory used
11 High Power Alarm
12 Low Power Alarm
Alarm 2 Value Value At Which Alarm 2 Activates
Dec 6161 22545 45090
RW
Limited by input scaling for alarm types 1 to 4.
Not used for alarms 5, 6 or 7.
0 to 100% for alarms 10 to 12.
Hex 1811 5811 B022
Alarm 2 Rate of Change Value Process Variable Rate of Change Alarm Threshold
Dec 6166 22550 45100
RW
Value for Rate of Change Alarm. Alarm 2 activates when PV
change exceeds this level. From 0.0 to 99999
Hex 1816 5816 B02C
Alarm 2 Hysteresis Alarm 2 Hysteresis Value
Dec 6162 22546 45092
RW
Deadband value (on “safe” side of alarm), through which signal
must pass before Alarm 2 deactivates.
Limited by the input scaling span
Hex 1812 5812 B024
Alarm 2 Inhibit Enable/disable Value Alarm 2 Power-up/Setpoint Change Inhibit
Dec 6163 22547 45094
RW
0 Disabled
Hex 1813 5813 B026
1 Enabled
