Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 174
Record Cascade Slave Primary Power Value Record Primary Power Value of Cascade Slave
Dec 7533 23917 47834
RW
0 Do Not Record Primary Power
Hex 1D6D 5D6D BADA
1 Record Primary Power Of Slave
Record Slave Secondary Power Value Record Slave Secondary Power in Cascade Mode
Dec 7538 23922 47844
RW
0 Do Not Record Secondary Power
Hex 1D72 5D72 BAE4
1 Record Secondary Power Of Slave
Record Ratio PV Input 1 Value Record Ratio Mode Input 1 Process Value
Dec 7534 23918 47836
RW
0 Do Not Record PV
Hex 1D6E 5D6E BADC
1 Record Ratio Input 1 PV Value
Record Ratio PV Input 2 Value Record Ratio Mode Input 2 Process Value
Dec 7535 23919 47838
RW
0 Do Not Record PV
Hex 1D6F 5D6F BADE
1 Record Ration Input 2 PV Value
Record Ratio SP Value Record Ratio Mode Setpoint
Dec 7536 23920 47840
RW
0 Do Not Record SP
Hex 1D70 5D70 BAE0
1 Record Ratio Mode SP Value
Record Ratio Power Value Record Ratio Mode Power Output Value
Dec 7537 23921 47842
RW
0 Do Not Record Ratio Power
Hex 1D71 5D71 BAE2
1 Record Ratio Mode Power
Trigger Recording On Alarm 1 Value Alarm 1 To Trigger Recording
Dec 7584 23968 47936
RW
0 Off
Hex 1DA0 5DA0 BB40
1 Trigger On Alarm 1 (if auto-trigger = profile or alarm)
Trigger Recording On Alarm 2 Value Alarm 2 To Trigger Recording
Dec 7685 24069 48138
RW
0 Off
Hex 1E05 5E05 BC0A
1 Trigger On Alarm 2 (if auto-trigger = profile or alarm)
Trigger Recording On Alarm 3 Value Alarm 3 To Trigger Recording
Dec 7686 24070 48140
RW
0 Off
Hex 1E06 5E06 BC0C
1 Trigger On Alarm 3 (if auto-trigger = profile or alarm)
Trigger Recording On Alarm 4 Value Alarm 4 To Trigger Recording
Dec 7687 24071 48142
RW
0 Off
Hex 1E07 5E07 BC0E
1 Trigger On Alarm 4 (if auto-trigger = profile or alarm)
Trigger Recording On Alarm 5 Value Alarm 5 To Trigger Recording
Dec 7688 24072 48144
RW
0 Off
Hex 1E08 5E08 BC10
1 Trigger On Alarm 5 (if auto-trigger = profile or alarm)
Trigger Recording On Alarm 6 Value Alarm 6 To Trigger Recording
Dec 7613 23997 47994
RW
0 Off
Hex 1DBD 5DBD BB7A
1 Trigger On Alarm 6 (if auto-trigger = profile or alarm)
Trigger Recording On Alarm 7 Value Alarm 7 To Trigger Recording
Dec 7614 23998 47996
RW
0 Off
Hex 1DBE 5DBE BB7C
1 Trigger On Alarm 7 (if auto-trigger = profile or alarm)
Sample Size Data Recording Sample Size
Dec 7595 23979 47958
RO
The size (in bytes) for recording sample with current settings
Hex 1DAB 5DAB BB56
