User Guide
1. Overview
1.7 Performance Specifications
Specification Non-Operational Operational
Vertical Rack Rail
Spacing
24 in. - 32 in.
1.7
Performance Specifications
Table 4: Performance Specifications
Specification Value
Number of Drive Slots 60
Data Transfer Rates 12Gbps SAS / 6Gbps SATA
Max Raw Data Storage Capacity 840 TB using 14TB HGST Ultrastar® HC530 drives
SAS Ports 12 x Mini-SAS HD ( 6 per IOM)
2 x 10/100/1G Ethernet
1.8
Ultrastar Data60 Layout
Figure 4: Front and Rear Product Layout
Table 5: Front and Rear Component Identification
Number Component
1 Enclosure Handles
2 CMAs
3 CMA Tray
4 Rear Fans
5 PSUs
6
