Western Digital Ultrastar Data60 - In HDD Assembly Layout

User Guide
2. Components
2.8 3.5in HDD Assembly
2.8.2 3.5in HDD Assembly Layout
Figure 32: 3.5in HDD Assembly Component Locations
Table 43: 3.5in HDD Assembly Component Descriptions
Number Feature
1 Latches
2 Latch Release
3 IO and Power Connectors
4 Drive Carrier
5 Disk Drive
