User Guide
2. Components
2.8 3.5in HDD Assembly
2.8
3.5in HDD Assembly
Figure 31: Ultrastar Data60 3.5in HDD
Assembly
The 3.5in HDD Assembly is comprised of two parts:
the storage drive and the drive carrier. The carrier
attaches to the exterior of the data storage drive and
caddies the drive into the enclosure. It stabilizes the
motion of the drive into the drive bay so that the
drive properly mounts onto the drive board.
2.8.1
3.5in HDD Assembly Specifications
Specification Value
Number per Enclosure up to 60 drives
Part Number See the List of Compatible Drives (page 22)
to find the specific part number required.
Hot Swappable? Yes
Weight .68 kg / 1.5 lbs.
52
