User Guide
4. Management
4.5 SES Page 02
curl -X POST -k -u admin:admin -H "Content-type: application/json"
https://<OOBM IOMA-IP Address>/redfish/v1/Chassis/IOModuleAFRU/Actions/
Chassis.Reset
curl -X POST -k -u admin:admin -H "Content-type: application/json"
https://<OOBM IOMB-IP Address>/redfish/v1/Chassis/IOModuleBFRU/Actions/
Chassis.Reset
4.5 SES Page 02
The SCSI Send Diagnostic and Receive Diagnostic Results commands can be addressed to a specific
SES element in the enclosure. There are many different element codes, such as Page 02, defined to cover
a wide range of devices. Page 02 refers to the control and status of the enclosure's PSUs, HDDs, ESMs, and
sensors.
Note: Refer to the SES Firmware Management Interface Specification for more information on
SES Page 02.
4.6 Zoning
Caution: Zone configuration should only be performed during a maintenance window, when
the system is offline (not in production).
4.6.1 Before Zoning
This section provides information on actions that should be taken before starting zoning on the Ultrastar
Data60 .
Users should install all of the required downloads before beginning the zoning process.
Required Downloads:
• SMP Tools 0.98 for Linux: http://sg.danny.cz/sg/smp_utils.html
• SG3 Utils: http://sg.danny.cz/sg/sg3_utils.html
• CLI Tools: to download the latest version, see Downloading Firmware from the Support Portal (page
161)
Recommended Downloads:
• WDDCS Tool – to download the latest version, see Downloading Firmware from the Support Portal
(page 161)
4.6.2 Predefined Zoning Configurations
There are four predefined zoning configurations for the Ultrastar Data60 . Each configuration connects
a different number of host ports to a set number of drives, called a zone group. This section provides
information about each of the predefined zoning configurations.
180
