Western Digital Ultrastar Data60 - CMA Cable Tray

User Guide
2. Components
2.7 CMA
2.7.3 CMA Cable Tray
Figure 30: Overview Image
The cable management assembly (CMA) comes with an optional tray that is used to support cable loads
greater than ten (five per arm). The CMA Cable Tray is mounted at the bottom-rear of the chassis using four
M3 x 8mm T10 Torx screws (two per side). It is useful in situations where cables might interfere with the
lower U space beneath the chassis.
